A dust suppression cannon was deployed in Saudi Arabia to control severe airborne dust generated during large-scale earthworks and material handling, resulting in improved site visibility, reduced dust dispersion, and more stable daily operations. The customer selected this solution in mid-2024 after traditional watering methods failed to meet dust control requirements under hot, dry, and windy conditions.
Click Here to Get A Free Quote
Dust Suppression Cannon Parameters
| Big Model | YG-50 | YG-60 | YG-80 | YG-100 | YG-120 |
| Spray Range | 50 meters | 60 meters | 80 meters | 100 meters | 120 meters |
| Spray Flow | 8 m³/h | 8 m³/h | 12 m³/h | 12 m³/h | 15 m³/h |
| Water Pump Stroke | 140 meters | 140 meters | 160 meters | 180 meters | 185 meters |
| Atomized Particles | 30-150 μm | 30-150 μm | 30-150 μm | 30-150 μm | 30-150 μm |
| Horizontal Rotation Angle | ±160° adjustable | ±320° adjustable | ±320° adjustable | 160° adjustable | 0-320° adjustable |
| Up and Down Pitch Angle | -5° to 35° | -5° to 35° | -5° to 35° | -10° to 45° | 0° to 60° |
| Total Power | 14.5 kW | 24.75 kW | 45.25 kW | 75 kW | 91 kW |
| Power Supply | 380V 50Hz three phase | 380V 50Hz three phase | 380V 50Hz three phase | 380V 50Hz three phase | 380V 50Hz three phase |
| Blower Motor Power | 11 kW | 18.5 kW | 37 kW | 55 kW | 75 kW |
| Water Pump Motor Power | 3 kW (Multistage centrifugal pump) | 5.5 kW (Multistage centrifugal pump) | 7.5 kW (Multistage centrifugal pump) | 11 kW (Multistage centrifugal pump) | 15 kW (Multistage centrifugal pump) |
| Noise Reduction Technology | Sinusoidal noise reduction | Sinusoidal noise reduction | Sinusoidal noise reduction | Sinusoidal noise reduction | Sinusoidal noise reduction |
| Lifting Mechanism | Hydraulic lifting | Hydraulic lifting | Hydraulic lifting | Hydraulic lifting | Hydraulic lifting |
| Left and Right Rotation Structure | High quality reduction motor | Hydraulic rotation | Hydraulic rotation | Hydraulic rotation | Hydraulic rotation |
| Number of Nozzles | 40 | 58 | 80 | 120 | 120 |
| Dimensions | 2000*1500*1500 mm | 1050*1600*2400 mm | 1400*1600*2500 mm | 2700*2000*2300 mm |
Click Here to Get A Free Quote
Project Background and Operating Environment
The project site was located in an open construction zone in Saudi Arabia, characterized by:
- High ambient temperatures
- Low humidity
- Frequent wind
- Fine sand and dry soil conditions
These factors caused dust to remain airborne for extended periods, affecting equipment operation, worker visibility, and surrounding areas.
Click Here to Get A Free Quote
Dust Control Challenges Faced by the Customer
Before equipment deployment, the customer encountered several issues:
- Manual watering could not control airborne dust effectively
- Dust spread beyond the work zone during loading and dumping
- High water consumption with limited suppression effect
- Reduced visibility for operators and haul trucks
The site required a dust control solution capable of addressing airborne dust rather than surface dust alone.
Why a Dust Suppression Cannon Was Selected?
After evaluating multiple options, the customer chose a dust suppression cannon as the core of the dust control solution.
Key selection reasons included:
- Long spray range suitable for open areas
- Fine mist capable of capturing airborne dust
- Adjustable spray angle and oscillation
- Compatibility with mobile and fixed deployment
Compared with ground spraying, the dust suppression cannon addressed dust at the source and reduced secondary dust generation.
Click Here to Get A Free Quote
Role of the Dust Suppression Machine on Site
The selected dust suppression machine was installed near active dust-generating zones, including:
- Excavation areas
- Aggregate loading points
- Temporary material stockpiles
The machine operated during peak dust periods rather than continuously, allowing targeted suppression with controlled water usage.
This approach improved dust control efficiency while minimizing unnecessary water consumption.
Integration into a Site Dust Suppression System
Rather than operating as a standalone unit, the dust cannon was integrated into a broader dust suppression system.
The system included:
- A centralized water supply with filtration
- Mobile deployment capability for shifting work zones
- Coordinated operation with loading and transport activities
This integration allowed the customer to adapt dust control measures to changing site conditions throughout the project lifecycle.
Click Here to Get A Free Quote
Results Achieved After Deployment
Following installation and adjustment, the customer observed:
- Noticeable reduction in airborne dust levels
- Improved visibility for operators and vehicles
- Lower dust migration beyond the site boundary
- More consistent working conditions during windy periods
The dust cannon enabled stable daily operations without interrupting construction progress.
Decision Logic and Configuration Considerations
The customer’s decision focused on operational fit rather than initial cost.
Key considerations included:
- Spray distance matched to site scale
- Diesel power for locations without fixed electricity
- Structural durability for high-temperature environments
- Ease of relocation as work areas changed
These factors ensured the dust suppression system remained effective throughout different project stages.
Click Here to Get A Free Quote
FAQ: Dust Suppression Cannon Use in Saudi Arabia
What affects the price of a dust suppression cannon?
Price depends on spray range, power type, mobility, control system, and material durability for harsh climates.
Is a dust cannon suitable for desert environments?
Yes. Dust suppression cannons are commonly used in dry, windy regions when configured with appropriate spray distance and mist density.
What is the difference between a dust cannon and manual watering?
A dust cannon controls airborne dust, while manual watering mainly suppresses surface dust and requires higher water consumption.
Can one dust suppression machine cover multiple work zones?
Yes. Mobile configurations allow relocation as dust sources shift across the site.
What maintenance is required?
Routine maintenance includes nozzle cleaning, pump inspection, and water filtration checks to ensure stable mist quality.
Click Here to Get A Free Quote
Dust Suppression Cannon in YG Machinery
This Saudi Arabia project demonstrates that a properly selected dust suppression cannon, combined with a well-planned dust suppression system, can effectively address dust challenges in harsh construction environments. By focusing on application needs and operational conditions, the customer achieved reliable dust control without disrupting productivity.
