A floor shot blaster is a specialized machine designed to clean, roughen, or prepare concrete surfaces using high-speed steel or ceramic shot. This process improves surface adhesion for coatings, overlays, or new concrete layers. It is suitable for contractors, industrial maintenance teams, and road construction companies seeking efficient surface preparation. The machine is often referred to as a concrete floor bead blaster or road shot blasting machine.
Click Here to Get A Free Quote
Floor Shot Blaster Parameters
| Model | YG-20 | YG-30 | YG-40 | YG-60 |
| Spraying distance | 20m | 30m | 40m | 60m |
| Engine | electric | electric | electric | electric |
| Electric | 380V/50HZ,3 phase | 380V/50HZ,3 phase | 380V/50HZ,3 phase | 380V/50HZ,3 phase |
| Fan motor | 3kw | 3kw | 4kw | 11kw |
| Steering motor | 2*1.5kw | 2*1.5kw | 2*1.5kw | 2*1.5kw |
| Pump motor | 1.5kw | 1.5kw | 2.5kw | 7.5kw |
| Horizontal angle | 360° | 360° | 360° | 360° |
| Vertical angle | Minus10°-55° | Minus10°-55° | Minus10°-55° | Minus10°-55° |
| The nozzle | 8 | 10 | 16 | 22 |
| Cylinder material | Q235 Carbon steel | Q235 Carbon steel | Q235 Carbon steel | Q235 Carbon steel |
| Bucket | 460L | 480L | 800L | |
| Water consumption | 1000L/h | 1500L/h | 3000L/h | 7500L/h |
| Recycled water pipe | 1400mm | 1400mm | 1400mm | 1400mm |
| The machine size | 1170*940*1700mm | 1170*940*1800mm | 1650*1200*2200mm | 1700*1200*2200mm |
| Weight | 200kg | 250kg | 300kg | 350kg |
Click Here to Get A Free Quote
Advantages of Floor Shot Blaster
- Consistent and efficient surface preparation with uniform roughness, reducing the need for rework and ensuring stable coating performance across large areas.
- Low operator fatigue design, allowing one-person control and continuous operation, even on long industrial projects.
- Integrated dust collection system, effectively capturing airborne particles to improve workplace safety and meet environmental standards.
- Reusable steel shot abrasive, which circulates in a closed-loop system, significantly lowering consumable and long-term operating costs.
- Flexible application capability, suitable for both small maintenance projects and large-scale industrial or infrastructure construction.
Applications of Floor Shot Blaster
- Industrial floors: Prepares concrete surfaces by removing laitance and weak layers, ensuring strong adhesion for epoxy, polyurethane, or anti-slip coatings used in factories and production plants.
- Roads and highways: Removes worn-out markings, rubber deposits, and surface contaminants while increasing friction, which improves vehicle grip and enhances driving safety in wet or high-speed conditions.
- Warehouses and factories: Creates a clean, rough, and durable surface that resists wear from forklifts, heavy machinery, and continuous traffic operation.
- Airports and parking areas: Efficiently treats large surface zones, improving skid resistance and ensuring consistent surface performance under heavy load and frequent vehicle movement.
A shot blasting machine for sale improves safety and reduces labor compared to manual grinding or acid-etching methods.
Click Here to Get A Free Quote
Working Principle and Configuration
- The machine propels high-speed steel or ceramic beads onto the floor.
- Impact removes debris, coatings, or weak concrete layers.
- Configurations vary by:
- Working width and blasting capacity
- Shot recovery system
- Motor power and drive type (electric or diesel)
- Mobility (manual push, ride-on, or automated)
Modern machines may include dust collection systems, adjustable blasting intensity, and ergonomic designs for operator comfort.
Factors Affecting Floor Shot Blaster Price
- Working width and productivity
- Motor type and power
- Dust collection and recycling system
- Brand reputation and warranty
- Additional features like adjustable blasting intensity
The price depending on machine type, capacity, and configuration.
Click Here to Get A Free Quote
How to Choose the Right Floor Shot Blaster?
- Match the machine’s width and productivity with your project size.
- Consider mobility: ride-on for large areas, push-behind for smaller spaces.
- Check compatibility with local electrical or diesel power sources.
- Evaluate dust collection and shot recycling capabilities.
- Review after-sales support, spare parts, and warranty.
Case Study: Thailand
In 2024, a Thai contractor purchased a floor shot blaster for airport runway maintenance. The client reported high efficiency, reduced surface preparation time, and improved coating adhesion compared to previous methods. This case demonstrates the suitability of shot blasting machines for sale in Southeast Asia.
Click Here to Get A Free Quote
FAQ about Floor Shot Blaster
Q1: What is the typical maintenance for a floor shot blaster?
A: Regular inspection of the shot wheel, brushes, and dust collector; replacement of worn parts is recommended.
Q2: Can it be used outdoors and indoors?
A: Yes. Machines with dust collection are suitable for indoor use, while ride-on or diesel-powered models handle outdoor applications.
Q3: What factors affect the price?
A: Machine width, motor type, shot recovery system, and additional features.
Q4: What surfaces can it prepare?
A: Concrete, asphalt, epoxy-coated floors, and worn industrial surfaces.
Q5: How does it differ from a concrete floor bead blaster?
A: Both terms describe similar machines, but bead blasters typically use finer steel beads for delicate surfaces, whereas floor shot blasters handle heavy-duty concrete and road surfaces.
Click Here to Get A Free Quote
floor shot blaster in YG Machinery
YG Machinery has over 20 years of experience in manufacturing and selling floor shot blasters, concrete bead blasters, and other surface preparation equipment. Our expertise ensures each machine delivers high efficiency, consistent performance, and long-term durability for industrial floors, roads, airports, and large-scale construction projects. With strict quality control and professional testing, YG machines meet international standards and are designed for safe, reliable operation. We also provide strong after-sales support, including spare parts, technical guidance, and maintenance services. Contractors, maintenance teams, and road construction companies worldwide trust YG Machinery for cost-effective, durable, and high-performance floor shot blasting solutions. Choosing YG ensures access to advanced technology, proven production experience, and reliable equipment that improves project efficiency and quality.
