A self loading concrete mixer truck is an integrated construction vehicle designed to mix, transport, and discharge concrete with minimal manual labor. It is widely used in construction sites, infrastructure projects, and remote areas where conventional concrete delivery is challenging.
What Is a Self Loading Concrete Mixer Truck?
A self loading concrete mixer truck combines a concrete mixer, loading bucket, and hydraulic system in a single vehicle. Operators can load raw materials, mix, transport, and pour concrete on-site without needing additional equipment. This makes it suitable for contractors, small construction companies, and municipal projects.
Key benefits include:
- Time-saving: Mix and deliver concrete in one vehicle.
- Labor-efficient: Requires fewer operators than traditional methods.
- Versatile: Can operate on rough terrain and remote areas.
- Accurate dosing: Hydraulic control ensures consistent mix ratios.
Click Here to Get A Free Quote
Self Loading Concrete Mixer Truck Parameters
| Category | Specifications |
| Model | CMT1500 |
| Rated Power | 55kW |
| Engine Model | Quanchai 4B2-75m22 |
| Dimensions (L×W×H)(mm) | 6400×2550×2650 |
| Wheelbase | 2400mm |
| Vehicle Weight | 4185kg |
| Driving Form | Torque converter |
| Maximum Climbing Angle | 30° |
| Minimum Turning Radius | 4700mm |
| Minimum Ground Clearance | 280mm |
| Maximum Speed | 30km/h |
| Gearbox Model | ZL-265 gearbox |
| Gearbox Gears | 4 forward 4 back |
| Water Tank Volume | 400L |
| Water Supply Method | Time relay |
| Fuel Tank Capacity | 63L |
| Oil Capacity | 16L |
| Hydraulic Capacity | 63L |
| Reducer | KY07-2-0 |
| Pump | FC 50/40 |
| Motor | BM5-160 |
| Drum Capacity | 1700L |
| Drum Rotation Speed | 13 rpm |
| Concrete Yield | 1.5 m³/can |
| Mixing Drum Features | Double helical agitating screw and convex bottom |
Click Here to Get A Free Quote
Advantages of Self Loading Concrete Mixer Trucks
- All-in-one operation: Loading, mixing, transporting, and pouring in one machine.
- Flexible working hours: On-demand concrete production reduces waste and wait times.
- Compact and mobile: Ideal for projects with limited space or rough access roads.
- Cost-effective: Reduces labor, transport, and batching plant costs.
Applications of Self Loading Concrete Mixer Trucks
Common usage scenarios include:
- Construction Sites: Building foundations, roads, bridges, and small-scale urban projects.
- Infrastructure Projects: Dams, tunnels, and remote facility construction.
- Industrial or Agricultural Sites: Concrete needs for warehouses, silos, or rural development.
self loading mixer truck sold to Thailand:
Our clients in Thailand used YG self loading concrete mixer trucks for a road and bridge project, achieving faster delivery and precise concrete quality. Many of these clients also use complementary equipment like our concrete pumps
for larger-scale concrete transfer.
Click Here to Get A Free Quote
Working Principle of self loading concrete mixer truck
- Loading: The front bucket loads sand, gravel, and cement into the mixer drum.
- Mixing: Hydraulic-driven rotation blends materials into consistent concrete.
- Transporting: The truck drives directly to the pouring site.
- Discharging: The drum tilts and pours concrete accurately at the target location.
Factors Affecting Self Loading Concrete Mixer Price
- Mixing capacity: Larger drum volumes increase the price.
- Engine type and power: Diesel vs. electric options affect cost.
- Hydraulic system quality: Higher-end systems offer smoother operation.
- Optional features: Remote control, adjustable chute, GPS, or automation.
- Brand and after-sales service: Reliable manufacturers like YG may have slightly higher upfront costs but lower lifetime maintenance expenses.
Click Here to Get A Free Quote
How to Choose the Right self loading mixer truck？
- Project size: Small sites may use 1–2 m³ trucks; large projects require 4–6 m³ models.
- Terrain: Rough or hilly areas require four-wheel-drive or crawler options.
- Frequency of use: High-demand sites benefit from more durable engines and hydraulic systems.
- Integration needs: If paired with concrete pumps or batching systems, ensure compatibility.
FAQ about self loading concrete mixer truck
Q1: What is the typical price range?
A: Self loading concrete mixer trucks range from $15,000 to $60,000, depending on capacity and features.
Q2: Can it operate in remote or hilly areas?
A: Yes, many models are designed for rough terrain and limited-access sites.
Q3: How much concrete can it mix at once?
A: Models typically range from 1 m³ to 6 m³ per batch.
Q4: Is it compatible with other concrete equipment?
A: Yes, it works seamlessly with concrete pumps and mobile batching plants.
Q5: What maintenance is required?
A: Regular checks of the drum, hydraulic system, engine, and lubrication reduce downtime and extend service life.
Click Here to Get A Free Quote
self loading concrete mixer truck in YG Machinery?
YG Machinery, based in Zhengzhou, China, has over 20 years of experience in manufacturing and exporting high-quality construction machinery. We specialize in self loading concrete mixer trucks, concrete pumps, mobile batching plants, and other construction equipment.
Our advantages include:
- Global reach: Equipment delivered to over 200 countries worldwide.
- Reliable quality: Rigorous testing ensures long-lasting performance.
- Professional support: Technical guidance, spare parts supply, and after-sales service.
- Custom solutions: Tailored configurations to meet specific project requirements.
With YG Machinery, clients benefit from efficient, cost-effective, and durable construction solutions, making us a trusted partner for projects of all sizes.
